Euro Slow Motion Hinge (2-4 Hole Mounting Plate)

Name: Euro Slow Motion Hinge (2 / 4 Hole Mounting Plate)
SKU: Euro Slow Motion Hinge, E-HSM, E-HSM1-M1, E-HSM1, E-HSM2, E-HSM3, EHSM1
Availability: InStock

₹0.00

Unique built in damping system allows the shutter to close in slow motion without banging. Available in Full overlay, Half overlay & Full Inset. Max opening 105° Max shutter size: 34″ x 22″ (850mm x 550mm) for 2 hinges. Shutter Thickness: 14mm to 22mm. Shutter cavity: Ø35mm, 12mm deep, cavity 4mm from edge.

1 in stock

SKU: Euro Slow Motion Hinge, E-HSM, E-HSM1-M1, E-HSM1, E-HSM2, E-HSM3, EHSM1

Category: Drawer Slides & Hinges, Ebco, Hinges, Regular / Euro Series

Description
Reviews (0)

Description

Unique built in damping system allows the shutter to close in slow motion without banging.
Available in Full overlay, Half overlay & Full Inset.
Max opening 105°
Max shutter size: 34″ x 22″ (850mm x 550mm) for 2 hinges.
Shutter Thickness: 14mm to 22mm.
Shutter cavity: Ø35mm, 12mm deep, cavity 4mm from edge.
